MG90S 180-Degree Servo Motor

MG90S 180-Degree Servo Motor

The MG90S is a compact and versatile servo motor capable of precise angular control, making it ideal for a wide range of robotics, automation, and hobbyist projects. With its 180-degree rotation capability and robust construction, the MG90S servo motor offers reliability and accuracy for various applications, including remote-controlled vehicles, robotic arms, and camera gimbals.

Key Features:

1. High Precision:
   • Provides accurate and precise angular control with a resolution of 1 degree.
   • Suitable for applications requiring precise positioning and motion control.
2. 180-Degree Rotation:
   • Offers a wide range of motion with a rotation angle of up to 180 degrees.
   • Enables versatile movement and positioning of attached components.
3. Compact Size:
   • Compact and lightweight design for easy integration into small-scale projects.
   • Allows for flexible mounting and installation options.
4. Durable Construction:
   • Features a durable metal gears for enhanced durability and longevity.
   • Withstands continuous operation and mechanical stress in various environments.
5. Universal Compatibility:
   • Compatible with a wide range of microcontrollers, such as Arduino, Raspberry Pi, and ESP32.
   • Can be controlled using PWM (Pulse Width Modulation) signals from the microcontroller.
6. Low Power Consumption:
   • Operates efficiently with low power consumption, making it suitable for battery-powered applications.
7. Plug-and-Play Operation:
   • Easy to use and install, requiring minimal setup for immediate operation.
   • Comes with three-pin connectors for convenient connection to the control circuit.

Specifications:

• Model: MG90S
• Operating Voltage: 4.8V – 6V
• Torque:
  • Stall Torque: 2.2 kg/cm (at 4.8V)
  • Operating Speed: 0.1 sec/60° (at 4.8V)
• Rotation Angle: 180 degrees
• Operating Temperature: -10°C to +50°C
• Dimensions: 22.8mm x 12.2mm x 28.5mm
• Weight: 13.4g

Applications:

• Robotics and Automation
• Remote-Controlled Vehicles
• Camera Pan-Tilt Mechanisms
• Robotic Arms and Grippers
• Aircraft and Drone Stabilization
• DIY Projects and Prototypes

Package Includes:

• 1x MG90S 180-Degree Servo Motor
• Mounting hardware

How to Use MG90S 180-Degree Servo Motor:

1. Power Supply:
   • Connect the servo motor’s power (VCC) and ground (GND) pins to the power supply (4.8V – 6V).
2. Control Signal:
   • Connect the control (signal) wire to a PWM-enabled pin on the microcontroller.
3. Write Control Code:
   • Write control code in the microcontroller to generate PWM signals to control the servo motor.
   • Adjust the pulse width to position the servo motor at the desired angle (0 to 180 degrees).
4. Attach Load:
   • Attach the load (e.g., arm, wheel, or camera) to the servo motor’s output shaft using appropriate mounting hardware.
5. Test and Calibrate:
   • Test the servo motor’s movement and calibration to ensure accurate positioning and smooth operation.
   • Fine-tune the control signals and mechanical setup as needed for optimal performance.
6. Integrate into Project:
   • Incorporate the MG90S servo motor into your robotics or automation project for motion control and manipulation tasks.

Explore the versatility and precision of the MG90S 180-Degree Servo Motor in your projects. Order now and unlock a wide range of motion control possibilities for your robotics and automation applications.
